Performance:
-Capable of hight RPM's for superior cleaning
-Water spray from the sides
-Utilizes fresh or reclaimed water
Structure:
-Constructed of 4" x 4" x 10 guage tubing
-Stainless steel #304
-Reinforced withh bolt sleeves
-No grease uhmw self lubricating curtain bushings
-Lifetime frame guarantee
Operation:
-TEFC electric fan cooled motor
-2 HP motor @ 1750 RPM
-Gearbox reducer @ 40:1 ratio
-Optional hydraulics available
| Specifications:
-Equipment height - 11'6"
-Vehicle clearance - 92"
-Width - 12'
-Electric - 220/208 volt 3 phase standard
-380/440 volt 50 cycle optional
-440/575 volt 60 cycle optional
-Hydraulic power optional
-Air - none
-Water - 3/4" PVC schedule 80
-Water nozzles - 10 - 1 GPM each standard
-Shipping weight - 1200 to 1800 lbs
-Tunnel length:
-Just mitter - 4'6"
-Mitter w/ baby rockers - 7'
|
